BLISSJUBILE

It is based on the loading principle developed for the Supreme Offering, a device using 4 coupled cavities with progressive damping leading to a front laminar vent. This proprietary charging principle significantly improves the system’s group propagation time.
Mechanical tensioning of the boomer thanks to a stainless steel threaded rod (non-magnetic) passing through the cabinet from one side to the other, resting on the boomer head and on the bottom of the cabinet. The tension is adjusted with a high-precision torque wrench to ensure the same tightening torque. This axial mounting of the bass driver allows for tensioning of the cabinet walls and ensures evenly distributed mechanical forces between the loudspeaker basket and the supporting baffle, which dramatically improves the transient response of the system.

Cells at 12dB/octave. Air coils wound with deoxygenated pure copper cable of 1.2mm diameter ensuring a dynamic without settling. Silver armature capacitors sorted in pairs with a tolerance of 1%. Non-inductive coil resistors.
Cut-off frequency 2800 Hz. Wiring “in the air” to reduce insertion loss and using our HP1132 silver cable. The whole filter is assembled on a specific anti-vibration support. It is positioned as far as possible from any magnetic and vibratory disturbance. WBT type terminal block accepting any type of connection (fork, banana or bare cable) on aluminum plate.

170 mm long fiber paper cone with Gaussian profile, treated on the inside with an extremely effective absorbent material. Flexible and inert polypropylene core cover. It has a 30 mm coil on a ventilated aluminum support, its aluminum frame clears the back of the cone perfectly. Its speeder is also ventilated to allow a better cooling of the coil and thus to lower significantly its distortion rate. It is equipped with a double magnet to increase the concentration of the magnetic flux on the coil. The suspension is made of a rubber-foam compound and has a progressive profile to achieve a very good return force in the extreme low frequencies while preserving the micro-displacements necessary for midrange reproduction.

The latter is none other than the one proudly displayed by our CANTABILEJUBILE model. A 28 mm impregnated silk dome tweeter particularly powerful. Its directionality is naturally very low, which allowed us to stop using a phase piece. Its linearity is exemplary and its internal damping optimal. It is driven by a powerful neodymium magnet, its very low resonance frequency allows us a cut-off frequency at 2800 Hz in 12 dB/octave. It is fixed with a specific glue to a machined aluminum horn for a better mechanical reference and to further improve its directivity and efficiency.

Thanks to the low directivity, it is not necessary to converge the two speakers to the ideal listening point, but to pinch them very slightly in order to make the most of the system’s phase.

The spacing will be determined experimentally. In theory, the ideal distance is about 2.5m from axis to axis, but this distance can be reduced or increased depending on the acoustic conditions and the dimensions of the listening room. In order to obtain a deep and well-built stereophonic image, make sure that the speakers are at least 40cm away from the side and rear walls.

*The best results in spectral balance and musicality were obtained by using our HP1132 cable, the same one used for the internal connection of all system components.
To optimize its performance in terms of bandwidth and sound image, it should be combined with the Magic Stand II. The long hours of listening necessary to its optimization and thus to validate its development were carried out on these supports.

This system has been developed for home use, in no case it can be used for public or private sound system.
Any incident resulting from such use is not covered by our warranty.
